Output Industrial LED Lighting Din Rail Type AC 220V Input DC 120W 24V 5A Breathing machine source power supply

$61.88

Din rail type  AC 220V Input DC 120W 24V 5A Output  industrial Switching power supply   120W Single Output Industrial DIN Rail Power Supply         DR-120 series Product showcase   Features:...

Din rail type  AC 220V Input DC 120W 24V 5A Output  industrial Switching power supply



120W Single Output Industrial DIN Rail Power Supply         DR-120 series

Product showcase





Features:
Protections: Short circuit/ Over load/ Over voltage/ Over temperature
Cooling by free air convection
Can be installed on DIN rail TS-35/7.5 or 15
LED indicator for power on
100% full load burn-in test
Fixed switch frequency at 55KHz
2 years warranty

Product Description



DR-120_01.jpgDR-120_02.jpgDR-120_05.jpgDR-120_06.jpgDR-120_07.jpgDR-120_08.jpgDR-120_11.jpg


SPECIFICATIONS

OUTPUT



Model

DR-120-12

DR-120-24

DR-120-48

DC Voltage

12V

24V

48V

Rated Current

10A

5A

2.5A

Current Range

0-10A

0-5A

0-2.5A

Rated Power

120W

120W

120W

Ripple & Noise

80mVp-p

80mVp-p

100mVp-p

Voltage Adj. Range

12-14V

24-28V

48-53V

Voltage Tolerance

±2%

±1%

±1%

Line regulation

±0.5%

±0.5%

±0.5%

Load regulation

±1%

±1%

±1%

Setup, Rise Time

500ms,70ms/230VAC   500ms,70ms/115VAC at full load

Hold Up Time

36ms/230VAC   32ms/115VAC at full load





INPUT



Voltage Range

88~132VAC/176~264VAC selected by switch   47~63Hz; 248~370VDC

AC Current

2.6A/115VAC   1.6A/230VAC

Efficiency

80%

84%

85%

Inrush Current

Cold start 20A/115V   40A/230V

Leakage Current

<3.5mA/240VAC





PROTECTION



Over Load

105%~150% rated output power

Protection type: Constant current limiting, recovers automatically after fault condition is removed

Over Voltage

15-16.5V

29-33V

58-65V

Protection type: Shut down o/p voltage, re-power on to recover

Over Temp.

85℃±5℃(TSW1)

90℃±5℃(TSW1)

90℃±5℃(TSW1)

Protection type: Shut down o/p voltage, recovers automatically after temperature goes down





ENVIRONMENT



Working Temp., Humidity

-10℃~+60℃; 20%~90% RH non-condensing

Storage Temp., Humidity

-20℃~+85℃; 10%~95%RH

Vibration

10~500Hz, 2G 10min./1cycle, period for 60min, each along X, Y, Z axes





SAFETY



Withstand Voltage

I/P-O/P: 3KVAC   I/P-FG: 1.5KVAC   O/P-FG: 0.5KVAC

Isolation Resistance

I/P-O/P, I/P-FG, O/P-FG: 100M Ohms / 500VDC/25℃/70%RH





STANDARD



Safety Standard

Design refer to UL508,UL60950-1,TUV EN60950-1

EMC Standard

Design refer to EN55011,EN55022,EN61000-3-2,-3,EN61000-4-2,3,4,5,6,8,11,EN55024,EN61000-6-2(EN50082-2), heavy industry level, criteria A
